Lift Tables

Lift Tables

These lift tables have over 30 different models to choose from, each built with different specifications, making them perfect for a wide variety of different tasks.

Models Available with 24" Wide Base:

 Model No. Capacity (lbs.)  Std. Plat. Base Low HT (In.) Raised HT (In.) Up Spead Volt/HP/HZ
SL24-20 2,000 24 x 36 9 33 15 Sec 115/1/60
SL24-40 4,000 24 x 36 9 33 21 Sec 115/1/60
SL24-60 6,000 24 x 36 9 33 32 Sec 115/1/60
SL36-20 2,000 24 x 48 9 45 20 Sec 115/1/60
SL36-30 3,000 24 x 48 9 45 30 Sec 115/1/60
SL36-40 4,000 24 x 48 9 45 37 Sec 115/1/60
SL36-50 5,000 24 x 48 9 45 40 Sec 575/3/60
SL36-60 6,000 24 x 48 9 45 48 Sec 575/3/60
SL42-20 2,000 48 x 84 9 51 25 Sec 115/1/60
SL42-40 4,000 48 x 84 9 51 47 Sec 115/1/60
SL42-60 6,000 48 x 84 9 51 50 Sec 575/3/60
SL48-20 2,000 48 x 96 9 57 32 Sec 115/1/60
SL48-40 4,000 48 x 96 9 57 50 Sec 115/1/60
SL48-60 6,000 48 x 96 9 57 56 Sec 575/3/60



Models Available with 36" Wide Base:
Designed for wider platform applications as these models have greater stability.

 Model No. Capacity (lbs.)  Std. Plat. Base Low HT (In.) Raised HT (In.) Up Spead Volt/HP/HZ
3SL24-20 2,000 36 x 36 9 33 15 Sec 115/1/60
3SL24-40 4,000 36 x 36 9 33 21 Sec 115/1/60
3SL24-60 6,000 36 x 36 9 33 32 Sec 115/1/60
3SL36-20 2,000 36 x 48 9 45 20 Sec 115/1/60
3SL36-40 4,000 36 x 48 9 45 37 Sec 115/1/60
3SL36-60 6,000 36 x 48 9 45 48 Sec 575/3/60
3SL42-20 2,000 36 x 60 9 51 25 Sec 115/1/60
3SL42-40 4,000 36 x 60 9 51 47 Sec 115/1/60
3SL42-60 6,000 36 x 60 9 51 50 Sec 575/3/60
3SL48-20 2,000 36 x 72 9 57 32 Sec 115/1/60
3SL48-40 4,000 36 x 72 9 57 50 Sec 115/1/60
3SL48-60 6,000 36 x 72 9 57 56 Sec 575/3/60



Models Available with 48" Wide Base:
Designed for wider platform applications as these models have greater stability.

 Model No. Capacity (lbs.)  Std. Plat. Base Low HT (In.) Raised HT (In.) Up Spead Volt/HP/HZ
4SL24-20 2,000 46 x 36 9 33 15 Sec 115/1/60
4SL24-40 4,000 46 x 36 9 33 21 Sec 115/1/60
4SL24-60 6,000 46 x 36 9 33 32 Sec 115/1/60
4SL36-20 2,000 48 x 48 9 45 20 Sec 115/1/60
4SL36-40 4,000 48 x 48 9 45 37 Sec 115/1/60
4SL36-60 6,000 48 x 48 9 45 48 Sec 575/3/60
4SL42-20 2,000 48 x 60 9 51 25 Sec 115/1/60
4SL42-40 4,000  48 x 60 9 51 47 Sec 115/1/60
4SL42-60 6,000  48 x 60 9 51 50 Sec 575/3/60
4SL48-20 2,000 48 x 72 9 57 32 Sec 115/1/60
4SL48-40 4,000 48 x 72 9 57 50 Sec 115/1/60
4SL48-60 6,000 48 x 72 9 57 56 Sec 575/3/60

Contact us today in order to start reducing the danger that may be occurring in your workplace!
