Wall Bracket Jib Crane, 5 Ton Capacity
A space-saving lifting solution that maximizes efficiency in tight work areas. Mounted on a wall, it provides a sturdy and reliable lifting mechanism. With its compact design and smooth rotation, it offers flexibility and convenience for various material handling tasks. Ideal for optimizing productivity and ensuring safe and precise load movement.
5 ton capacity wall bracket jib cranes are one of the most economical means of providing hoist coverage for individual use in bays, along walls or columns of plants, or as a supplement to an overhead crane or monorail system. The low dead weight of the boom and the bronze brushings and oil-impregnated bronze thrust washers provide easy rotation and superior load positioning for these jib cranes. The formed bracket fittings on these wall bracket jib cranes provide greater reliability as there are no welds in tension and all bolts are in double shear for increased strength.
Lifting Equipment
We have a variety of lifting equipment available to improve the ergonomics of your facility and reduce injuries.
Gripper End of Arm Tooling
This Gripper End of Arm Tooling device was designed with the automotive industry in mind.
Pneumatic Device for Transfer Cases
This pneumatic lifting device has a power clamp and power lift, in addition to having the ability to manually rotate 180 degrees.
Manual Lifting Attachment
One of our customers needed a solution to lift 11 camshafts. R&D Ergo Ltd.
- This jib crane allows operators to position loads precisely, effortlessly and efficiently.
- Formed bracket fittings on this jib crane provide greater reliability
Jib Crane Models
| Span (A) | Model Number | B | D | E | F | G | W | Tie Rod Diameter |
| 8′ | WB100-G5-8-W8 | 3′ 0″ | 1′ 6″ | 15-1/4″ | 6″ | 7″ | 8″ | 2″ |
| 10′ | WB100-G5-10-W10 | 3′ 3″ | 1′ 6″ | 15-1/4″ | 6″ | 7″ | 10″ | 2″ |
| 12′ | WB100-G5-12-W10 | 4′ 0″ | 1′ 9″ | 15-1/4″ | 6″ | 7″ | 10″ | 2″ |
| 14′ | WB100-G5-14-W12 | 4′ 9″ | 2′ 0″ | 15-1/4″ | 6″ | 7″ | 12″ | 2″ |
| 16′ | WB100-G5-16-W12 | 5′ 6″ | 2′ 6″ | 15-1/4″ | 6″ | 7″ | 12″ | 2″ |
| 18′ | WB100-G5-18-W12 | 6′ 3″ | 3′ 0″ | 15-1/4″ | 6″ | 7″ | 12″ | 2″ |
| 20′ | WB100-G5-20-W16 | 7′ 0″ | 3′ 6″ | 15-1/4″ | 6″ | 7″ | 16″ | 2″ |
| 24′ | WB100-G5-24-W12c10 | 8′ 9″ | 3′ 6″ | 15-1/4″ | 6″ | 7″ | 12″ | 2″ |
| 30′ | WB100-G5-30-W16c10 | 11′ 0″ | 3′ 6″ | 15-1/4″ | 6″ | 7″ | 16″ | 2″ |
