Mast Type Jib Crane, 1/4 Ton Capacity
A space-saving lifting solution with a vertical mast for enhanced stability. Ideal for confined areas, it offers efficient load handling and precise maneuverability.
These 1/4 ton capacity mast type jib crane is floor supported, top stabilized and is capable of 360-degree rotation through a top and bottom bearing assembly. These jib cranes are simple and efficient in design and usually require no special foundation making them one of the most cost-effective 360-degree rotation system jib cane on the market.
Gripper End of Arm Tooling
This Gripper End of Arm Tooling device was designed with the automotive industry in mind.
Manual Lifting Attachment
One of our customers needed a solution to lift 11 camshafts. R&D Ergo Ltd.
Clamp End Effector
This factory decided that it needed a faster more effective way to move around delicate, but heavy parts.
- These jib cranes use a self-aligning radial brushing at the top which cannot be displaced, and an identical self-aligning radial brushing at the bottom which, when used with an oil-impregnated bronze thrust washer, provides ease of movement.
Jib Crane Models
| Capacity | OAH (C) | 8′ Span | 10′ Span | 12′ Span | 14′ Span | 16′ Span | 18′ Span | 20′ Span |
| 1/4 Ton | 10′ | MT400-8-6-15 | MT400-8-6-15 | MT400-8-6-15 | MT400-8-8-15 | MT400-8-8-15 | MT400-10-8-15 | MT400-10-8-15 |
| 1/4 Ton | 12′ | MT400-8-6-15 | MT400-8-6-15 | MT400-8-6-15 | MT400-8-8-15 | MT400-8-8-15 | MT400-10-8-15 | MT400-10-8-15 |
| 1/4 Ton | 14′ | MT400-8-6-15 | MT400-8-6-15 | MT400-8-6-15 | MT400-8-8-15 | MT400-10-8-15 | MT400-10-8-15 | MT400-10-8-15 |
| 1/4 Ton | 16′ | MT400-8-6-15 | MT400-8-6-15 | MT400-8-6-15 | MT400-8-8-15 | MT400-10-8-15 | MT400-10-8-15 | MT400-10-8-15 |
| 1/4 Ton | 18′ | MT400-8-6-15 | MT400-8-6-15 | MT400-8-6-15 | MT400-8-8-15 | MT400-10-8-15 | MT400-10-8-15 | MT400-10-8-15 |
| 1/4 Ton | 20′ | MT400-8-6-15 | MT400-8-6-15 | MT400-8-6-15 | MT400-10-8-15 | MT400-10-8-15 | MT400-10-8-15 | MT400-14-8-15 |
