Hydra-Lift Drum Roller and Safety Enclosure

To lift your drum from upright into position for rolling Hydra-Lift Drum Rollers use ergonomic powered hydraulics. This can save you time, labour and money by mixing the contents of the drum while it is still inside the closed drum.

By using a Hydra-Lift Drum Roller you will be able to eliminate the splashing of dangerous contents on workers, spills and the risks of contamination. This drum handling unit also does the work of loading and unloading itself, again reducing the amount of work that you will have to complete when mixing drums.

The Hydra-Lift Drum Roller has a capacity of 1,000 pounds for liquid loads and a 400-pound capacity for dry loads. This is because a shifting dry load puts more stress on the drum rotator than the fluid motion of a liquid load. You can roll a drum 6” to 26” in diameter and with a 40” maximum length.

A Control Package is sold separately and can be selected with the model and power supply in mind. The power controls start the drum rolling and the control mast can be positioned outside the safety enclosure.

Technical Specifications:

Attachment Dimensions Movement Weight
Designed To.
Eliminate transfer and cleanup by using a separate drum for each batch, having no container purge between batches and having nothing to insert into the drum.
Motor Models.
1-phase electric motor, 3-phase electric motor, an explosion proof 1-phase electric motor, an explosion proof 3-phase electric motor and an air motor.
Movement
AC Control Package and an Explosion Proof AC Control Package.
Weight Capacity.
1,000 lbs
Controls Fall Safety User
Designed With.
A timer, start & stop buttons, a red emergency stop button, 24V DC control supply, and lockable main disconnect to shut off & lock out power to the unit.
Controls.
24V DC control supply
Safety Features
Built-in safety feature controls prevent accidental release of the drum
Number of Users.
1 User


Video of Drum
 Handling Unit in Action:

Contact us today in order to start reducing the danger that may be occurring in your workplace!
